Proxalo Hardware

Built from the ground up. Designed from the inside out.

We studied proven unattended-service, locker, kiosk and parcel systems, learned from their strongest principles and limitations, then engineered our own architecture. Every view on this page comes from the production CAD.

Own cabinet, electronics, locking and sensing USPTO patent filed Pick-Up: 1030 × 2069 × 652 mm

01 Drop-Off unit

The unit that runs the access point.

Touchscreen, scanner, label printer, industrial computing and communication, UV-C and sensing — seventeen parts in one cabinet.

Drop-Off unit

Exploded view · 17 parts · from the assembly drawing
Drop-Off cabinet Front panel Antenna Industrial communication module Status light bar Electronic lock Fan 21.5″ touchscreen display Barcode / QR scanner UV-C sterilization & ventilation system Ultrasonic load sensor Ultrasonic and UV lamp installation board Upper hopper door Lower basket access door Basket Accessible audio-navigation keypad Label printer outlet Industrial computing module (IPC) Label printer
  1. 01 Antenna
  2. 02 Industrial communication module — Wi-Fi / 4G / 5G / Bluetooth
  3. 03 Status light bar
  4. 04 Electronic lock
  5. 05 Fan
  6. 06 21.5″ touchscreen display
  7. 07 Barcode / QR scanner
  8. 08 UV-C sterilization & ventilation system
  9. 09 Ultrasonic load sensor
  10. 10 Ultrasonic and UV lamp installation board
  11. 11 Upper hopper door — electronic lock
  12. 12 Lower basket access door
  13. 13 Basket
  14. 14 Accessible audio-navigation keypad
  15. 15 Label printer outlet
  16. 16 Industrial computing module (IPC)
  17. 17 Label printer

02 Pick-Up unit

Where completed orders wait.

Ten electronically locked compartments with infrared occupancy sensing and hanging rods. No screen, no controller — it takes its orders from the Drop-Off.

Pick-Up unit

Exploded view · 17 parts · from the assembly drawing
Pick-Up cabinet weldment Infrared occupancy sensors Infrared occupancy sensors Hanging rods and 6th-generation control locks Hanging rods and control locks Right electronically controlled doors Left large electronically controlled doors Top electronics deck Cabinet side panel
  1. 01 IoT limit plate
  2. 02 Switching power supply protection
  3. 036th-generation electric control lock ×10
  4. 04 Bluetooth communication module
  5. 05 Cabinet weldment
  6. 06 Data acquisition board
  7. 07 Door state sensors
  8. 08Footing, M12×80 with nut, SUS304 ×4
  9. 09Hanging rod ×10
  10. 10Infrared occupancy sensor — receiving optocoupler ×10
  11. 11Infrared occupancy sensor — transmitting optocoupler ×10
  12. 12Left emergency component ×3
  13. 13Left large electronically controlled door ×6
  14. 14Right electronically controlled door ×4
  15. 15Right emergency component ×2
  16. 16 Socket mounting plate 2
  17. 17 Switching power supply, 12 V 8.5 A

Pick-Up unit · live 3D

Explodes on view · drag to rotate

Loading model…

  • 05 Cabinet weldment
  • 12/15 Emergency components, left and right
  • 13/14 Ten electronically controlled doors — 6 left, 4 right
  • 03/09 Ten 6th-generation control locks and ten hanging rods
  • 10/11 Ten infrared occupancy sensor pairs
  • 01/02/04/06/07/16/17 IoT limit plate, Bluetooth module, data acquisition board, door-state sensors, socket plate, 12 V switching supply
  • 08 Four M12 SUS304 levelling feet

Measured from the CAD: 1030 × 2069 × 652 mm

03 Pilot program

See it on your wall.

One Drop-Off plus one or more Pick-Up units, sized to the building. We provide, install and run it.
